Alco Locomotive Parts
Strict standards and guidelines are followed in the production of these Alco locomotive parts. Essential spares like cylinder heads, black sleeves, precision-turned parts, and piston crowns make up our inventory. Our Alco parts are made from premium stainless steel and are resistant to corrosion and dust buildup, so they will last a long time on the track.
Bosch Fuel Pump Parts
| Sr. No. | Part Description | Alco Part No. |
|---|---|---|
| 1 | Adjusting Washer | 9431030124 |
| 2 | Adjusting Washer | 9431030123 |
| 3 | Adjusting Washer | 9431030125 |
| 4 | Adjusting Washer | 9431030126 |
| 5 | ALCO Nut | 9411033302 |
| 6 | Baffle Ring 2322652-1 | 9411030203 |
| 7 | Banjo Bolt 2401442 | 9411033407 |
| 8 | Bush 2322164-1 | 9411030336 |
| 9 | Control Rod | 2321379 9411036000 |
| 10 | Control Rod Guide | 9411033401 |
| 11 | Cover 2321533 | 9411030002 |
| 12 | Delivery Valve 23213611 | 9411038503 |
| 13 | Delivery Valve 2321368 | 9411038505 |
| 14 | Delivery Valve Holder 2321349-1 | 9411033301 |
| 15 | Diesel Filter Insert | 1457431003 |
| 16 | Distance Piece | 9431030120 10244888 |
| 17 | Element 2321267 | 9411038401 |
| 18 | Element | 2321294 |
| 19 | Element 4321091 | 9411038402 |
| 20 | Element | 1418360033 |
| 21 | Feed Pump | F002A50001 |
| 22 | Fillister Head Screw | 2910022196 |
| 23 | Flat Seal Ring | 2916710605 |
| 24 | Flat Seal Ring | 2916710611 |
| 25 | Flat Seal Ring | 2916710613 |
| 26 | Fuel Inlet Connection | 2433370117 |
| 27 | Gasket | 2440109005 |
| 28 | Indicator | 1410098000 |
| 29 | Injector | 9430032141 |
| 30 | Inlet Union | 1903385013 |
| 31 | Inlet-Union Screw | 2911202705 |
| 32 | Intermediate Disc | 2430136000 |
| 33 | Latch 2322662 | 9411032003 |
| 34 | Lower Spring Plate 2322384 | F002F61003 |
| 35 | Nozzle 4231051-1 | 9430033301 10330665 |
| 36 | Nozzle 22310219-9 | 9430033300 |
| 37 | Nozzle | 9430033302 |
| 38 | Nozzle + Nozzle holder (Nh Assy) | 9430032130 |
| 39 | Nozzle + Nozzle holder (Nh Assy) | 9430032131 |
| 40 | Nozzle Cap Nut | 9431033320 |
| 41 | Nozzle Holder 22312410-2 | 9430031302 |
| 42 | Nozzle Holder | - |
| 43 | Nozzle Holder | 9430031300 |
| 44 | Nozzle Holder Body | 9431035132 |
| 45 | Nozzle Retaining Nut | 2433314085 |
| 46 | Nozzle Retaining Nut | 2433314087 |
| 47 | O-Ring 2321325 | 9411030201 |
| 48 | O-Ring 2321327-1 [2321326] | 9411030202 |
| 49 | Plunger Guide 2321304 | F002f61002 |
| 50 | Pointer 2321355 | 9411030000 |
| 51 | Pressure Bolt | 9431033107 |
| 52 | Pump Hosing 2321338 | 9411035206 |
| 53 | Regulating Sleeve / Sleeve Control 2321445-1 | 9411036300 |
| 54 | Screw Excisable | 9411033400 |
| 55 | Sealing Washer F002f60001 | 1410107005 |
| 56 | Shim 23210321 | 9411030105 |
| 57 | Shim 23210318 | 9411030106 |
| 58 | Shim 23210322 | 9411030107 |
| 59 | Shim 23210323 | 9411030108 |
| 60 | Shim 23210324 | 9411030109 |
| 61 | Shim 23210325 | 9411030110 |
| 62 | Shim 23210319 | 9411030111 |
| 63 | Shim | 2430100600 |
| 64 | Shim | 2430100601 |
| 65 | Shim | 2430100602 |
| 66 | Shim | 2430100603 |
| 67 | Shim | 2430100604 |
| 68 | Shim | 2430100605 |
| 69 | Shim | 2430100606 |
| 70 | Shim | 2430103005 |
| 71 | Shim | 2430103006 |
| 72 | Single Cylinder Fuel Pump 2320016-3 | 9410035000 2320016-2 |
| 73 | Single Cylinder Pump 4320021-1 | 9410035001 |
| 74 | Single Cylinder Pump | 0414621004 |
| 75 | Single Cylinder Pump | 0414951013 |
| 76 | Snubber Valve 2402466 | 9411037400 |
| 77 | Spindle | 2433122003 |
| 78 | Spindle | 2433124040 |
| 79 | Spring 2321393 | 9411034601 |
| 80 | Spring 2321464 | 9411034602 |
| 81 | Spring | 9431034601 |
| 82 | Spring (ALCO) 2322094 | 9411034600 |
| 83 | Spring Disc | 2430120000 |
| 84 | Steel Washer | 9431030128 |
| 85 | Upper Spring Plate 2321316 | 9411030503 |
| 86 | Washer 2322083 | 9411030003 |
Fuel Pump Related Parts
| Sr. No. | Part Description | Alco Part No. |
|---|---|---|
| 1 | Air Nozzle | 22610464 |
| 2 | Auxiliary Spring Retainer - Lower | 4321021 |
| 3 | Auxiliary Spring, Fuel Pump Cross Head, Inner | - |
| 4 | Auxiliary Spring, Fuel Pump Cross Head, Outer | - |
| 5 | Fuel Injection Tube | 4401031-1 |
| 6 | Fuel Primary Filter | - |
| 7 | Fuel Pump Cross Head | 2320193 |
| 8 | Fuel Pump Cross Head Cam Roller | - |
| 9 | Fuel Pump Cross Head Lifter | 23215911-1 |
| 10 | Fuel Pump Cross Head Lifter Assembly | - |
| 11 | Fuel Pump Inlet Machine (Header To Fuel Pump) | - |
| 12 | Fuel Pump Support Crosshead And Lifter Unit | - |
| 13 | Fuel Pump Support Wide Cam | 23210226 |
| 14 | Fuel Pump Support Wide Cam | 23210214-1 |
| 15 | Fuel Secondary Filter | - |
| 16 | Primary Fuel Filter | - |
| 17 | Lifter Fuel Pump Cross Head | 2322592 |
| 18 | Lifter Fuel Pump Cross Head | 4321033 |
| 19 | Lifter Push Rod (Air & Exhaust) | 2240201-1 |
| 20 | Secondary Fuel Filter | - |
Alco Gaskets
| Sr. No. | Part Description | Alco Part No. |
|---|---|---|
| 1 | Gasket-Lub Oil Filter Strainer | - |
| 2 | Gasket Manifold To Super Charger | 21536512 |
| 3 | Gasket Flex Italic For Manifold | 21536515 |
| 4 | Gasket Elbow To Cyl. Elbow | 2152238 |
| 5 | Gasket Over Water Conn. Cyl. Head | 2152239 |
| 6 | Gasket Manifold To Turbo & Elbow | 2153654-1 |
| 7 | Gasket Circular Water Conn. Cyl. Head | 2152237 |
| 8 | Gasket Fuel Inl Conn. To Pump | 2153595, 10170509 |
| 9 | Gasket Conn. To Inlet Casing Single | 21536511 |
| 10 | Gasket Turbine Oil Seal | 41510163 |
| 11 | Gasket Mounting Bracket For Ge Gov. | - |
| 12 | Gasket Water Outlet Collector | - |
| 13 | Gasket Over Speed Trip, Upper & Lower | - |
| 14 | Gasket Lub Oil Pump To End Plate | - |
| 15 | Gasket Water Pump Spacer Plate | - |
| 16 | Gasket Cover To Housing | - |
| 17 | Gasket For Cyl. Block Gen. End | - |
| 18 | Gasket Back Plate Lo Pump | - |
| 19 | Gasket Lub Oil Pump Face Plate | - |
| 20 | Gasket Brg. Frame To Casing | - |
| 21 | Gasket For Bearing Housing Tech. Generator | - |
| 22 | Gasket Extension Shaft Oil Seal | - |
| 23 | Gasket Ext. Shaft Oil Seal To Turbo Support | - |
| 24 | Gasket Fuel Pump Support | - |
| 25 | Gasket Control Compartment Cover To Cyl. Block | - |
| 26 | Gasket Final Stage Fuel Oil Filter | - |
| 27 | Gasket Oil Seal Retainer To Diaphragm | - |
| 28 | Gasket Vibration Damper Camshaft L.S. | - |
| 29 | Gasket Explosion Door | - |
| 30 | Gasket Base Door | - |
| 31 | Gasket For Air Pipe At Turbo Charger | - |
| 32 | Gasket Air Pipe At Turbocharger End | - |
| 33 | Gasket Main Brg. Lub Oil Header To Main Base | - |
| 34 | Gasket Over Speed Trip To Cylinder Block | - |
| 35 | Gasket Seal Plate Water Pump | - |
| 36 | Gasket Water Outlet Header To Cyl. Head | - |
| 37 | Gasket Water Inlet Pipe To Cyl. Block | - |
| 38 | Gasket Water Pump Discharge Pipe | - |
| 39 | Gasket For Water Pump Discharge Pipe | - |
| 40 | Gasket After Cooler Water Piping | - |
| 41 | Gasket Turbo Support To Cylinder Block | - |
| 42 | Gasket Bet. Gear Casing & Base L.S. | - |
| 43 | Gasket A/C Centring Late | - |
| 44 | Gasket After Cooler To Turbo Support | - |
| 45 | Gasket Cover To Aftercooler | - |
| 46 | Gasket Bottom Cover To After Cooler | - |
| 47 | Gasket For Oil Catcher Gen. End | - |
| 48 | Gasket Turbine Casing And Intermediate Casing | - |
| 49 | Gasket Ring To Flange Brg. Lub Oil Header | - |
| 50 | Gasket Crankcase Ventilation Blower To Elbow | - |
Alco Gasket Kits
| Sr. No. | Part Description | Alco Part No. |
|---|---|---|
| 1 | Gasket Kit For Cyl. Liner Upper & Center | - |
| 2 | Gasket Kit (Copper) | - |
| 3 | Kit For Gasket (Copper) | - |
| 4 | Kit For Gasket (Rubber) | - |
| 5 | Gasket Kit 6 Cyl. | 2501066-5 |
| 6 | Gasket Kit 12 Cyl. | 25010610-7 |
| 7 | Gasket Kit 16 Cyl. | 25010624-1 / 25010611-5 |
| 8 | Gasket Kit 1 Cyl. | 2501067-6 |
| 9 | Gasket Set | 25010627 |
| 10 | Gasket Kit 16 Power Cylinder | - |
| 11 | Gasket Kit 16 Power Cylinder | - |
ALCO Hoses
| Sr. No. | Part Description | Alco Part No. |
|---|---|---|
| 1 | Hose Flexible For Filter To Header | - |
| 2 | Hose Flexible For Inlet To Outlet | - |
| 3 | Hose Flexible For Fuel Return From | - |
| 4 | Hose Flexible For L O To Filter Upper | - |
| 5 | Hose Flexible For L O To Filter Lower | - |
| 6 | Hose Flexible For L O To Filter Upper | - |
| 7 | Hose Flexible For L O To From Filter | - |
| 8 | Hose Flexible For L O To Filter Center | - |
| 9 | Hose Flexible For L O To Filter Lower | - |
| 10 | Hose Flexible For Relief Valve To Base | - |
| 11 | Hose Flexible For Elbow To Tube | - |
| 12 | Hose Flexible For L O To Governor | - |
| 13 | Hose Flexible For L O From Governor | - |
| 14 | Hose Flexible For Water Pipe From Turbo | - |
| 15 | Hose Flexible For Water Pipe From Gas | - |
| 16 | Hose Flexible | - |
| 17 | Hose Flexible | - |
| 18 | Hose Flexible For Filter | - |
| 19 | Hose Assembly | - |
| 20 | Hose Flexible Drain From Ls Pamper | - |
| 21 | Hose Spl Flexible Drain From Rs Damper | - |
| 22 | Hose Flexible Blower To Gear Cover 'V' Engine | - |
Bolts
| Sr. No. | Part Description | Alco Part No. |
|---|---|---|
| 1 | Bolt "T" F/ALCO 251 | 1601511-2 |
| 2 | Bolt Axle Cap | - |
| 3 | Bolt Lever Fulcrum | - |
| 4 | Bolt With Nut (ASSLY) | - |
| 5 | Bolt, SPL, Con, Rod To Cap | 2171052 |
| 6 | Brake Head Bolt | - |
| 7 | Mounting Bolt | - |
| 8 | Ream Bolt 5/8 - 11 * 3-5/8 | 21526818 |
| 9 | Special Bolt | 2261143 |
| 10 | Special Bolt Nozzle Clamp | 2151429-5 |
| 11 | Special Bolt To Turbo |
Nuts
| Sr. No. | Part Description | Alco Part No. |
|---|---|---|
| 1 | Handle Nut | 2241471 |
| 2 | Hug Lock Nut | |
| 3 | Hug Lock Nut | |
| 4 | Hug Lock Nut | |
| 5 | Hug Lock Nut 5/8 - 11 | 21513727 |
| 6 | Lock Nut | |
| 7 | Lock Nut | |
| 8 | Lock Nut | 2155826-1 |
| 9 | Lock Nut (For Adjusting Screw) | 2241251-1 |
| 10 | Locking Nut - Fan Drive Gear | |
| 11 | Locknut 7/16" F/ALCO 251 | 2155829 |
| 12 | Nut | |
| 13 | Nut | |
| 14 | Nut | |
| 15 | Nut - Connecting Rod Bolt | 2151022 |
| 16 | Nut (Cam Shaft Gear) | 2155172 |
| 17 | Nut (Cylinder Head Big) | 2153174 |
| 18 | Nut (Cylinder Head Small) | 2153175 |
| 19 | Nut (Ext. Shaft) | 10220136 |
| 20 | Nut 3/8 | 2151692-1 |
| 21 | Nut Centre | |
| 22 | Nut Hex | 2151625-1 |
| 23 | Nut Hex | 2151626-1 |
| 24 | Nut SP, Con. Rod Boll Cotter Pin, Nut Locking, 1/8'' 1-1/4' Long | 2151021 |
| 25 | Nut Special | |
| 26 | Nut, 5/8"-11 Sq. HD | 2153873 |
| 27 | Nut, Elastic Stop 5/8"-11 | 21513742 |
| 28 | Nut, Nozzle Clamp, 5/8-11 In | 2151691-1 |
| 29 | Nut, Special, Injection Tube Stud | 21516311 |
| 30 | Nut, SPL | 2153271 |
| 31 | Nut, SPL Locking | 4151036 |
| 32 | Special Hex Nut | 21552210-1 |
| 33 | Special Nut | |
| 34 | Special Nut | 2155891 |
| 35 | Special Nut (For H.O. Tube) Long | |
| 36 | Special Nut Assembly For Exhaust Manifold | |
| 37 | SPL Nut Assembly | 21552225 |
| 38 | Wing Nut (Centre) | |
| 39 | Wing Nut (Centre) | |
| 40 | Wing Nut (Inter) | |
| 41 | Wing Nut (Lub Oil Strainer) | 1601371-1 |
Pins
| Sr. No. | Part Description | Alco Part No. |
|---|---|---|
| 1 | Cotter Pin – Centre Main Brg. | 21514079 |
| 2 | Cotter Pin Int. Main Brg. | 21514047 |
| 3 | Cotter Pin Nut | |
| 4 | Dowel Pin 1/2" DIA | 2151054 |
| 5 | Fulcrum Pin | 4321063 |
| 6 | Fulcrum Pin | |
| 7 | Fulcrum Pin | 23216010 |
| 8 | Fulcrum Pin For A & E Push Rod Lifter | 2241353-1 |
| 9 | Fulcrum Pin For Fuel Pump Lifter | |
| 10 | Hanger Pin | |
| 11 | Headed Pin | |
| 12 | Lever Pin | |
| 13 | Pin | 2241354-1 |
| 14 | Pin | |
| 15 | Pin | |
| 16 | Pin | |
| 17 | Pin | 2241535-1 |
| 18 | Pin (Cam Roller) | |
| 19 | Pin (Cam Roller) | |
| 20 | Pin Control Leakage | |
| 21 | Pin Cotter Intermediate 7/16 X 2 1 / 2 | |
| 22 | Pin Cotter Intermediate 7/16 X 2 1 / 2 | |
| 23 | Pin Cotter, Nut To Spindle | 20514029 |
| 24 | Pin Idler Gear | |
| 25 | Pin Motor Suspension | 1411069 |
| 26 | Pin Spacer Thrust Shoe | 2261223 |
| 27 | Pin Yoke To Link | |
| 28 | Pin, Keeper, Motor Suspension | 1411221 |
Screws
| Sr. No. | Part Description | Alco Part No. |
|---|---|---|
| 1 | Adjusting Screw | 2321564-1 |
| 2 | Adjusting Screw | 2241101 |
| 3 | Adjusting Screw Seat | 2322532 |
| 4 | Adjusting Screw Yoke | 2151921-1 |
| 5 | Cap Screw | |
| 6 | Cap Screw | 2320261 |
| 7 | Cap Screw | 23211320 |
| 8 | Cap Screw 3/4-10, 5-1/2 | 21523510 |
| 9 | Cap Screw Special Gear Sections | 2155632 |
| 10 | Cap Screw Special Inlet To Header | 2155942 |
| 11 | Cap Screw 1/2-In-13 X 5-3/4-In. F/ALCO 251 | 21513578 |
| 12 | Cap Screw 3/8 In-16 X 2-3/4 In F/ALCO 251 | 21513571 |
| 13 | Cap Screw Bracket - Flange 5/8-11x1-1/2" | 2151352-1 |
| 14 | Cap Screw, Barring Device To Mounting Bracket 1/2-13x1/2 In | 21513513-1 |
| 15 | Cap Screw, Elbow To Block (1/2-13x1-1/4) | 21513510-1 |
| 16 | Seat Adjusting Screw | |
| 17 | Set Screw, 1/4-20 X 3/8 Soc. HD | 2152073 |
| 18 | Slotted Screw | 21558145 |
| 19 | Stainless Steel Screw 5/16" - 18 Threads Per Inch | 21512863 |
EMD Miscellaneous Parts
| Sr. No. | Part Description | EMD Part No. |
|---|---|---|
| 1 | Adjusting Screw | 8052327 |
| 2 | Air Filter | 11664253 |
| 3 | Air Filter Assy | 40043929 |
| 4 | Air Inlet Duct | 40062584 |
| 5 | Bearing Ball Carrier | 40015822 |
| 6 | Bearing Carrier Drive Shaft Gear | 9416636 |
| 7 | Bearing Commutator Side | 8864951P65 |
| 8 | Block ASM... Bearing - Drilled Cap | 9542904 |
| 9 | Block ASM... Bearing - Plain Cap | 9542905 |
| 10 | Bolt | 8159340 |
| 11 | Bolt | 8242193 |
| 12 | Bolt ½” – 13 | 7884 |
| 13 | Bolt ASM | 8127868 |
| 14 | Bracket ASM... Bearing - Left Bank ACC End | 9544055 |
| 15 | Bracket ASM... Bearing - Left Bank Cam Shaft End | 9543649 |
| 16 | Bracket ASM... Bearing - Right Bank ACC End | 9544051 |
| 17 | Bracket ASM... Bearing - Right Bank Cam Shaft End | 9543492 |
| 18 | Bracket Bearing | 8069712 |
| 19 | C Link | 9528663 |
| 20 | Cap Main Brg | 9541512 |
| 21 | Cap Main Brg | 9541511 |
| 22 | Cap Main Brg | 9541514 |
| 23 | Cap Main Brg | 9090608 |
| 24 | Cap Main Brg | 5141514 |
| 25 | Cap Main Brg Centre | 8476507 |
| 26 | Cap Main Brg Centre | 16140886 |
| 27 | Cap Main Brg Genene | 8476509 |
| 28 | Cap Main Brg Genene | 16140862 |
| 29 | Cap Main Brg Inter | 8476510 |
| 30 | Cap Main Brg Inter | 16140874 |
| 31 | Car Body ASSM With Part Drawing | 40074009 |
| 32 | Carrier Bearing Retainer | 40039257 |
| 33 | Carrier Bolt / Bolt Hex Head 5/16 | 40039256 |
| 34 | Carrier EMD 645 E | 8367800 |
| 35 | Chamber Gasket Cooper | 40055466 |
| 36 | Chart-Grommet Strip | 9565052 |
| 37 | Chart-Shim | 8452073 |
| 38 | Clutch Dowelling ASM | 40001043 |
| 39 | Clutch Drive Assembly | 40001044 |
| 40 | Collar | 8320743 |
| 41 | Collar Adjustment | 8034849 |
| 42 | Collar | 8028464 |
| 43 | Conduit | |
| 44 | Counterweight Lb Front | 9545408 |
| 45 | Counterweight Lb Rear | 40033553 |
| 46 | Counterweight Rb Front | 40052883 |
| 47 | Counterweight Rb Rear | 40033554 |
| 48 | Cylinder Test Valve Assembly | 40035242 |
| 49 | Elbow | 8360557 |
| 50 | Elbow | 9534873 |
| 51 | Elbow Ems 40 | 8436703 |
| 52 | Elbow Lube Oil Pressure | 8436704 |
| 53 | Elbow Water Outlet Rb | 8346547 |
| 54 | Elbow Water Out Lt Lb | 8346691 |
| 55 | Elbow Water Outlet | 8414444 |
| 56 | Fuel Oil Line | 8039842 |
| 57 | Fuel Oil Line ASM | 8160209 |
| 58 | Inj Cont Shaft ASM Lb | 8196855 |
| 59 | Inj Cont Shaft ASM Rb | 8196856 |
| 60 | Inner Race 645 | 8135970 |
| 61 | Insert, Lower Liner, Crankcase & Oil Pan Asy | 8168641 |
| 62 | Lever | 8215509 |
| 63 | Lever | 8194651 |
| 64 | Lever Reset | 8029623 |
| 65 | Lube Oil Manifold End | 8288093 |
| 66 | Manifold Adapter Turbo Filter | 8366249 |
| 67 | Manifold -Centre | 8288094 |
| 68 | Nut Head To Liner / Hex Nut 3/4-16 | 8060089 |
| 69 | Ost Cover ASM | 9573981 |
| 70 | Rocker Arm Shaft | 8028460 |
| 71 | Roller 645 | 9319503 |
| 72 | Shaft ASM Lb | 8320751 |
| 73 | Shaft ASM -Ost | 8320750 |
| 74 | Y Flange | 8289021 |
Studs & Stud Bolts
| Sr. No. | Part Description | Alco Part No. |
|---|---|---|
| 1 | Special Stud | |
| 2 | Stud | |
| 3 | Stud | |
| 4 | Stud | |
| 5 | Stud (L.O.P.) | |
| 6 | Stud Bolt | 21514280-1 |
| 7 | Stud Bolt | 10215402 |
| 8 | Stud Bolt (Centre) BG | 2151609-1 |
| 9 | Stud Bolt (Inter) BG | 215607-1 |
| 10 | Stud Bolt (Mg) | |
| 11 | Stud Bolt Int. Bg. | 2151607-1 |
| 12 | Stud Bolt Inter | |
| 13 | Stud For Fuel Pump Support | |
| 14 | Stud In Support | 21514267-1 |
| 15 | Stud Turbo | |
| 16 | Stud, Seal Plate To Frame | 21535222 |
Shims
| Sr. No. | Part Description | Alco Part No. |
|---|---|---|
| 1 | Shim | |
| 2 | Shim (350 Turbo Charger) | |
| 3 | Shim, Air Seal To Oil Seal | |
| 4 | Shim, Upper Spring Seat, 0.002 In | 2231411 |
| 5 | Shim, Upper Spring Seat, 0.004 In | 2231412 |
| 6 | Shim, Upper Spring Seat, 0.008 In | 2231413 |
| 7 | Shim, Upper Spring Seat, 0.020 In | 2231414 |
| 8 | Shim, Upper Spring Seat, 0.042 In | 2231415 |
Equaliser & Shafts
| Sr. No. | Part Description | Alco Part No. |
|---|---|---|
| 1 | Air Damper Shaft | |
| 2 | Armature Shaft | |
| 3 | Armature Shaft | |
| 4 | Fulcrum Brake Equaliser | |
| 5 | Fork Link For Motor Mod. 251-C | 2321898 |
| 6 | Equaliser Short End (LH) | 11022670 |
| 7 | Equaliser Short End (LH) | 11022668 |
| 8 | Equaliser Short End (RH) | 11022607 |
| 9 | Equaliser Short End (RH) | 11022590 |
| 10 | Equaliser Lower Portion | |
| 11 | Equaliser Pin | |
| 12 | Equaliser Pin | |
| 13 | Equaliser Pin | |
| 14 | Equaliser Spring Seat BG | |
| 15 | Equaliser Spring Seat BG | |
| 16 | Equaliser Spring Seat BG | |
| 17 | Equaliser Spring Seat MG | |
| 18 | Propeller Shaft | 2361975 |
| 19 | Propeller Shaft | 1670288 |
| 20 | Propeller Shaft | 2361975 |
| 21 | Propeller Shaft | 1670288 |
| 22 | Propeller Shaft | 1670282 |
| 23 | Shaft | |
| 24 | Shaft | 2241324 |
| 25 | Shaft | |
| 26 | Shaft Bearing For Booster | 2251201 |
| 27 | Shaft Drive | 2361185 |
| 28 | Shaft Drive Horizontal | |
| 29 | Shaft For T.M. | |
| 30 | Shaft Key | 21512716 |
| 31 | Shaft PN | 2261329 |
| 32 | Shaft Valve Lever | 2241322-5 |
| 33 | Shaft, Lever Arm Ost | 2361319 |
| 34 | Drive Shaft Woodward Governor | |
| 35 | Extension Shaft (BG) | 21901313 |
| 36 | Extension Shaft (BG) | |
| 37 | Extension Shaft (MG) | 21901316 |
| 38 | Fan Shaft | 4281102 / 10211810 |
| 39 | Idler Shaft For Lub Oil Pump (BG) | 2391325-1 |
| 40 | Spline Shaft | 4281103 |
| 41 | Stepped Free Shaft | 2391322 |
| 42 | Straight Free Shaft | 2391326-1 |
| 43 | Support Valve Lever Shaft | 2241283 |
Sleeves
| Sr. No. | Part Description | Alco Part No. |
|---|---|---|
| 1 | Sleeve | 4281221 |
| 2 | Sleeve | 2251284-2 |
| 3 | Sleeve (Water Pump Shaft) | |
| 4 | Sleeve Fully Finished | 2322353 |
| 5 | Sleeve Push Rod | |
| 6 | Sleeve Shaft | 2251283 |
| 7 | Sleeve Stud Jacket | |
| 8 | Sleeve: Bottom Shirt, 10-1/4 x 10-11/16 x 2-1/2 in, Black, Cast Iron, Flanged, Without Admission Hole And Without Inner Bottom Chamfer | 2311062-1 |
Gear Casing
| Sr. No. | Part Description | Alco Part No. |
|---|---|---|
| 1 | Gear Case Assembly | |
| 2 | Gear Case Assembly (BG) | |
| 3 | Gear Case Assembly Complete For TM 4907 | |
| 4 | Gear Case Assembly For 165/M For Motor DRG NO. NDLA/MO-124 ALT-5 | |
| 5 | Gear Case Assembly For Wdm3a TO BHEL DRG. NO. 04391613004&003 | |
| 6 | Gear Case ASSLY 165m (Top & Bottom Halves) | |
| 7 | Gear Case ASSLY For T/M 4303 CZ 1400 Hp | |
| 8 | Gear Case ASSLY Metric For Traction Motor-165m | |
| 9 | Gear Case Complete Unit Including Top & Bottom Halves Capacity 9kg. For Tm4907 With PTFE Seal | |
| 10 | Gear Case Half Wiper Ring Comp. T | |
| 11 | Gear Case Oil Filling Cover | |
| 12 | Gear Casing | 4281091 |
| 13 | Gear Casing A/C Fan Drive | |
| 14 | Locos Top Half Bottom Half Gear Case RDSO Drawing No. SKDP 3196 Alt-1 And SKDP 3197 Alt-1 |
Vibration Damper
| Sr. No. | Part Description | Alco Part No. |
|---|---|---|
| 1 | Vibration Damper | 2160201 |
| 2 | Vibration Damper | 2190016 |
| 3 | Vibration Damper Complete (Paddle Wheel) | |
| 4 | Vibration Shock Absorber | 2190015-1 |
Miscellaneous Parts
| Sr. No. | Part Description | Part No. |
|---|---|---|
| 1 | Amphenol Connector 16 Pin | 8453146 |
| 2 | ST Connector | 8482180 |
| 3 | ST Connector | 8482180 |
Alco Bearings
| Sr. No. | Part Description | Part No. |
|---|---|---|
| 1 | Bearing (Blower END with Trilobe) | 2261204-2 |
| 2 | Bearing Shell Con Rod (Upper) | 21710226 |
| 3 | Big END Bearing/Con Rod Bearings | 13022556 |
| 4 | Big END Bearing/Con Rod Earing’s | 13971542 |
| 5 | Big END Bearing/Con Rod Earing’s | 13971529 |
| 6 | Big END Bearing/Con Rod Earing’s | 13971517 |
| 7 | Blower END with Trilobe For Larger Thrust Area 12 Cyl & 16 Cyl 2600 BHP Engine | 2161204-2 |
| 8 | Clearance Brg. For Cam Shaft | 13070265 |
| 9 | Con Rod (Cap Only) Brg Lower - 2286 Mm | 21710233 |
| 10 | Con Rod (Cap Only) Brg Lower (1016 Mm) | 21710231 |
| 11 | Con Rod (Cap Only) Brg-Lower | 21710228 |
| 12 | Con Rod (Rod Only) Brg Upper (2286 Mm) | 21710239 |
| 13 | Con Rod Bearing STD | 11383320 |
| 14 | Con Rod Bearing Upper (1016 Mm) | 21710237 |
| 15 | Fitted Bearing for Cam Shaft | 13070046 |
| 16 | Main Bearing Shell Centre STD | 21410326 |
| 17 | Main Bearing Shell STD | 21410166 |
| 18 | Main Bearing Shell Thrust | 21410365 |
| 19 | Main Bearing Shell Thrust | 21410366 |
| 20 | Main Clearance Bearing for Crank Shaft | 13022570 |
| 21 | Main Clearance Bearing for Crank Shaft | 13971554 |
| 22 | Main Clearance Bearing for Crank Shaft | 13971505 |
| 23 | Main Clearance Bearing for Crank Shaft | 13971591 |
| 24 | Piston Pin Bearing | 13030267 |
| 25 | Piston Pin Bearing | 13030218 |
Alco Bushes
| Sr. No. | Part Description | Part No. |
|---|---|---|
| 1 | Bushing (Cam Shaft Bushing) | 2161332 |
| 2 | Bushing (Piston Pin END Connecting Rod) | 2171016 |
| 3 | Bushing (Valve Lifter) | 2241491 |
| 4 | Bushing Out Board | 10150833 |
| 5 | Valve Lever Bushing | 2153638-1 |
| 6 | Valve Lever Bushing | 2153632 |
Alco Turbocharger
| Sr. No. | Part Description | Part No. |
|---|---|---|
| 1 | Bearing Blower END with Trilobe | 10150766 |
| 2 | Bearing Turbine END with Trilobe | 22612012 |
| 3 | Blower-END Bush Regular (Without Trilobe) | 2261208 |
| 4 | Floating Bushing | 2261527 |
| 5 | Floating Bushings | 4261091 |
| 6 | Thrust Washer | 2261139 |
| 7 | Turbine-END Bush Regular (Without Trilobe) | 2261209 |
EMD Switches
| Sr. No. | Part Description | Part No. |
|---|---|---|
| 1 | Switch | 8441983 |
| 2 | Switch ...Magnetic.B12, 24-M2, 23, 34 -Repl. 8335901 | 8464114 |
| 3 | Switch ...Magnetic.B21, 31, 32, 42, 51, 65, M16, 34, 36. Replaces 8328962 | 8464113 |
| 4 | Switch ...Magnetic.B32, B42, B51, B65, M36 | 8464116 |
| 5 | Switch ...Magnetic-RVF, RVR-Without Motor Cut-Out | 8464117 |
| 6 | Switch ...Slide...Iso...SW | 8330131 |
| 7 | Switch Rotary Snap | 8213093 |
| 8 | Switch Slide | 8455355 |
| 9 | Switch Slide Button. Control & Fuel Pump, Engine Run, Gauge Lights | 8330135 |
| 10 | Switch... Slide Button A-B Norm. Open | 8330133 |
| 11 | Switch...Rotary-Headlight-4 Pos.-4 POLE-Except 9510341 | 8243533 |
| 12 | Switch...Snap | 40009667 |
| 13 | Switch...Toggle...Cab Light | 8004611 |
EMD Sensors
| Sr. No. | Part Description | Part No. |
|---|---|---|
| 1 | Sensor Assembly...Etp1 7 Etp2 | 40029233 |
| 2 | Sensor...Pu | 40038643 |
| 3 | Traction Motor Speed Sensor | 40142706 |
| 4 | Traction Motor Temperature Sensor | 40171676 |
